NX Wing OBSIDIAN

NX Wing OBSIDIAN

S/. 18,900.00
S/. 18,900.00
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.

Nx WING

Los Equipos Obsidian son traídos a Pedido segun proyecto. Comunicarse al 921456541 ó por WhatsApp: 997554167 para consultas.

NX Wing is the complementary USB control surface to Obsidian Control Systems ONYX platform. Based on the NX 2 console the NX Wing utilizes the same rugged design and components with an identical footprint and layout. Through its USB connection the NX Wing provides a responsive, professional hardware surface to operate ONYX on any PC system without compromises. Any user of ONYX will feel instantly familiar with the NX Wing and no setup or additional installation is required. Simply plug it into a user-provided PC with ONYX and get started instantly.

NX Wing provides extensive connectivity with 4 DMX Ports, MIDI and Timecode ports while unlocking 64 Universes of control when connected to ONYX on a PC.



Botones/Faders/TouchScreen:

  • 10x 60 mm playback faders, each with 4x function-assignable buttons
  • 8x customizable multi-function keys
  • Playback Select button
  • Master Go section with Go, Pause, Snap and Release
  • 4x digital rotary encoders with push function and status LED for fixture parameter control
  • 3.5" RGB touchscreen for parameter groups, effect parameters, fanning and global timings
  • Grand master rotary fader and button
  • Blind/HighLight/Last/Next buttons
  • Full numerical keypad and command keys
Conexiones:
  • 4x DMX / RDM Universe In/Out: 5pin locking XLR
  • MIDI in/out/thru (MIDI Show Control, MIDI notes, MIDI Timecode): 5pin DIN (temporarily unavailable)
  • SMPTE Timecode In/Out: 3pin XLR (temporarily unavailable)
  • 12 VDC power supply input: 4pin XLR
  • Desk lamp: XLR 12V
  • USB In: USB 2.0 B



Please note that due to ongoing supply chain disruptions the NX Wing may not have the Timecode and Midi ports installed. Required parts will be shipped to all affected customers at a later time at no charge.



Key Features

  • Fully featured control surface, portable and lightweight
  • 10 Playbacks, Encoders, Keypad and internal 3.5" touchscreen
  • DMX, Timecode and Midi Connectivity (temporarily unavailable)
  • ONYX Premier 64 Universe License
  • Plug and Play USB device for any PC with ONYX
